Product feature:
● Thread size from 1/2″, 3/4″, 1″;
● Spray angle is wide angle full cone spraying, 90 degree;
● Material is plastic/PP;
● The vane can be removable;
● Produce full cone spray, the spray area is circular;
● Unlimited internal circulation channel and could produce uniform distribution under the high-pressure & large flow rate, easy to control the spraying flow, the blade design;
● Compeletly cover the injection area;
● Integral stucture, fit for small to medium flow spray;
At 3 bar pressure, the flow rate are:
1/2 inch (Orifice size is 7mm) : 28 L/min;
3/4 inch (Orifice size is 8mm) : 45 L/min;
1 inch (Orifice size is 9m) : 56 L/min.
Applications:
● Phosphating of metal parts
● Car rain test
● High pressure washing
● Chemical cleaning of printed circuit boards
● Mirror-making silver plated
● Paper mill mesh roll cleaning
● Food Industry Beverage Bottle Cleaning
● SO2 removal
● Nitric oxide control
● Steelmaking and continuous casting cooling
● Exhaust gas scrubbing
● Quenching and Cooling
● Fire fighting and fire protection
● Dust control
● Defoaming
● Spray application
